EVO STH

    0%
    • 545 STH
    • 720 STH
    • 1000 STH
    • 1200 STH

    Horizontal Bandsaw Machines

    Automatic machines for bars
    Robust and reliable saws for steel, capable of enviable performance thanks to the studies carried out on the high-speed cutting of high tensile alloys, hardened and chromed steels.

    Models

    The characteristics shown in the table are not binding and may differ from the current models, please contact us for more details.

    Features545 STH720 STH1000 STH1200 STH
    Cutting (mm)550 x 550720 x 7201000 x 10001200 x 1200
    Blade size (mm)6800 x 419300 x 5411000 x 5412300 x 67
    Corsa carro (mm)450450450450
    Blade motor power (kW)7,5111517
    Weight (Kg)12000140002000022000
    Features545 STH
    Cutting (mm)550 x 550
    Blade size (mm)6800 x 41
    Corsa carro (mm)450
    Blade motor power (kW)7,5
    Weight (Kg)12000
    Features720 STH
    Cutting (mm)720 x 720
    Blade size (mm)9300 x 54
    Corsa carro (mm)450
    Blade motor power (kW)11
    Weight (Kg)14000
    Features1000 STH
    Cutting (mm)1000 x 1000
    Blade size (mm)11000 x 54
    Corsa carro (mm)450
    Blade motor power (kW)15
    Weight (Kg)20000
    Features1200 STH
    Cutting (mm)1200 x 1200
    Blade size (mm)12300 x 67
    Corsa carro (mm)450
    Blade motor power (kW)17
    Weight (Kg)22000
