NOVA NCH
0%
- 1500 NCH-3
- 1500 NCH-4
- 2000 NCH-3
- 2000 NCH-4
- 2000 NCH-6
Automatic moving arc saws
High efficiency plate saws
NCH plate saws are designed for quick and accurate cutting of bars and plates into strips of varying widths. This allows you to reduce inventories of cut-to-width- stock and increase the flexibility of your sawing operation. Models are available in a wide range of sizes. High-productivity Automatic machines, with moving arc from 4 to 6 meters cutting length.
Models
The characteristics shown in the table are not binding and may differ from the current models, please contact us for more details.
Features | 1500 NCH-3 | 1500 NCH-4 | 2000 NCH-3 | 2000 NCH-4 | 2000 NCH-6 |
---|---|---|---|---|---|
Cutting (mm) | 1500 x 300 | 1500 x 300 | 2000 x 800 | 2000 x 800 | 2000 x 800 |
Blade size (mm) | 9100 x 41 | 9100 x 41 | 10200 x 41 | 10200 x 41 | 10200 x 41 |
Blade motor power (kW) | 11 | 11 | 15 | 15 | 15 |
Weight (Kg) | 1400 | 1500 | 1700 | 1800 | 2000 |
Bow stroke (mt) | 3 | 4 | 3 | 4 | 6 |
Features | 1500 NCH-3 |
---|---|
Cutting (mm) | 1500 x 300 |
Blade size (mm) | 9100 x 41 |
Blade motor power (kW) | 11 |
Weight (Kg) | 1400 |
Bow stroke (mt) | 3 |
Features | 1500 NCH-4 |
---|---|
Cutting (mm) | 1500 x 300 |
Blade size (mm) | 9100 x 41 |
Blade motor power (kW) | 11 |
Weight (Kg) | 1500 |
Bow stroke (mt) | 4 |
Features | 2000 NCH-3 |
---|---|
Cutting (mm) | 2000 x 800 |
Blade size (mm) | 10200 x 41 |
Blade motor power (kW) | 15 |
Weight (Kg) | 1700 |
Bow stroke (mt) | 3 |
Features | 2000 NCH-4 |
---|---|
Cutting (mm) | 2000 x 800 |
Blade size (mm) | 10200 x 41 |
Blade motor power (kW) | 15 |
Weight (Kg) | 1800 |
Bow stroke (mt) | 4 |
Features | 2000 NCH-6 |
---|---|
Cutting (mm) | 2000 x 800 |
Blade size (mm) | 10200 x 41 |
Blade motor power (kW) | 15 |
Weight (Kg) | 2000 |
Bow stroke (mt) | 6 |
